1. Product Introduction
Composition
Body part: stator, rotor
Supporting part: Front and rear end caps, bearings
Sensing part: Hall components
Features
Fast response, large starting torque, less electromagnetic radiation, high efficiency, good reliability, wide range of speed regulation, strong generality, strong resistance to radio interference, low noise, good insulating property, low cost of maintenance, small size, long service life
Advantage of Removing Brush
The DC brushless motor has the excellent speed control characteristic of the DC motor. As the brush is removed, there is no commutation spark and no regular maintenance is needed. Compared with the brush product, the brushless product has lower noise, longer life and smaller electromagnetic interference.
How to Achieve Low Interference and Low Noise
Our product itself has the characteristic of low interference. The adoption of optimized structural design and precision ball bearing enables it to have low vibration and low noise.
How to Achieve More Energy-efficient
Adopting high-performance rare earth magnets not only makes the brushless motor smaller in size than the DC brush type and the AC type products but also makes it more efficient. In addition, VVVF and other technologies can be used, which can greatly reduce energy consumption.
Application
Industrial automation (Textile machinery, door opening equipment), household appliance, car, office automation (printer), medical equipment
2. Certification
Our product has obtained CE and RoHS certification. If customers need, we can also apply for the UL certification.
3. Optional Accessories
The shape, shaft length, shaft diameter, lead length and lead color can be designed according to customer requirements. The output shaft can be equipped with pulley or gear. Connectors can be installed for the leads. The motor can be equipped with gearbox, encoder, brake, external drive and built-in drive.
4. Notes
A. Select the drive according to the operating voltage of the motor. The voltage should be within the voltage range of the drive.
B. Peak current = rated power×4/rated voltage. The peak current of the selected drive should approach or exceed the value calculated according to the above formula.
C. Since the drive has speed setting and PI control, it should match the motor's number of pole and maximum speed. The drive should be recommended by our staff.
D. The winding leads of the motor may interfere with the Hall signal line, so they should be wired separately. When the winding lead is longer than 500mm, it is suggested to use a shielded wire to separate from the Hall signal line.
